OVS-6

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameOVS-6
Application fieldapplication as generator in aircraft altimeter
Cathode typeimpregnated, indirect heating
Output typecoaxial
Envelopemetal-ceramic
Mass650g
Cooling methodnatural
Frequency range4400-4200MHz
Power irregularity in frequency band, dB6
Output power250mW
Tuning steepness2-3MHz/V
Filament voltage, V6,3
Filament current, A1
