GMI90

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameGMI90
Typepulse tetrode
Application fieldpulse feeding to magnetron
Cathode typeoxide, indirect heating
Envelopeglass with base
Mass1,3kg
Cooling methodair
Dimensions250mmx145mm
Output power140W
Filament voltage25V
Filament current6,5 - 7,8A
Maximum anode voltage33kV
Pulse duration3uS
