NameGS31B
Typetriode
Application fieldOscillation UHF power up to 360W, up to 1070MHz in special equipment
Brief applicationHF amplification, oscillation
Cathode typeoxide, indirect heating
Envelopemetal-ceramic
Mass1.2 kg (650 g)
Cooling methodforced air (other)
Dimensions147mmx100mm (134mmx65mm)
Output power1 kW
Maximum operating frequency1030 MHz
Filament voltage12.6 V
Filament current3.1 - 3.7 A
Maximum anode voltage1.5 kV
Mutual conductanceat least 22 mA/V
