KIU-15

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameKIU-15
TypePulse, Amplificative
Application fieldUHF signal amplification in special equipment
Cathode typeOxide, indirect heating
Envelopemetal, waveguide output/coaxial input
Mass80kg
Cooling methodforced water
Frequency band1818MHz
Output power30MW in pulse
Gain, dB37dB
Filament voltage, V10,3-12,7
Filament current, A50
Pulse anode voltage, kV270-300kV
