KIU-19

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameKIU-19
TypePulse, Amplificative
Application fieldUHF amplification in transmitters
Cathode typeOxide, indirect heating
Envelopemetal-ceramic, coaxial input and output
Mass20kg
Frequency band1029,8-1030,2MHz
Output power75W/35kW in pulse output//3W input
Gain, dB40dB
Filament voltage, V12,6
Filament current, A2,2-2,6A
Pulse anode voltage, kV30kV
