KIU-41B

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameKIU-41B
TypePulse, Amplificative
Application fieldapplication as frequency converter in power transmitter
Cathode typeOxide, indirect heating
Envelopemetal-ceramic with magnets
Mass4,5kg
Cooling methodconductive
Frequency band1299MHz (IF=35MHz)
Output power1kW
Filament voltage, V6,3
Filament current, A0,8-1,4
Pulse anode voltage, kV4,5kV
