KU-103

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameKU-103
TypeAmlificative
Application fieldapplication as aplifier and freq.converter in radiorelay communicators
Cathode typeOxide, indirect heating
Envelopemetal, waveguide output, mechanical tuning
Mass1,1kg
Cooling methodforced air
Frequency band6385-5965MHz
Output power3W
Gain, dB7,8dB
Filament voltage, V6,3
Filament current, A2,3
Resonator voltage, V500
