KU-301

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameKU-301
TypeAmlificative
Application fieldapplification as last-stage power amplifier in transmitter
Cathode typeOxide, indirect heating
Envelopemetal
Mass65kg
Cooling methodforced air
Frequency band30-31cm
Output power10kW
Gain, dB40dB
Filament voltage, V8
Filament current, A55-70
Pulse anode voltage, kV14-16kV
