KU-316

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameKU-316
TypeAmlificative
Application fieldapplication as power amplifier in transmitters
Cathode typeimpregnated, indirect heating
Envelopemetal-ceramic, waveguide output/coaxial input
Mass4kg
Frequency band4287MHz
Output power3,3kW
Gain, dB40dB
Filament voltage, V12,6
Filament current, A2,8
Pulse anode voltage, kV9-11kV
