NameMI-316
TypePulse
Application fieldapplication in meteorology radars
Cathode typeindirect heating
Envelopemetal-ceramic
Mass, kg13,5
Cooling methodforced air
Frequency range9580-9610MHz
Output power250kW
Frequency pulling, MHz12
Tuning steepness1MHz/A
Filament voltage, V12,6
Filament current, A3,5-4,5
Anode voltage, kV21-25
External loading agreement coefficient1,1-1,3
Pulse duration, uS1
Space factor or pulse repeating frequency0,0005
