NameMI-320
TypePulse
Application fieldapllication as UHF generator in industrial equipment
Cathode typeoxide, indirect heating
Envelopemetal-ceramic, not-batched
Mass, kg70
Cooling methodforced water
Frequency range1883-1889MHz
Output power9-11kW/9-11MW in pulse
Frequency pulling, MHz6
Filament voltage, V5,0-10
Filament current, A190-210
Anode voltage, kV50
External loading agreement coefficient1,5
Pulse duration, uS5
Space factor or pulse repeating frequency200Hz
