NameMI-328
TypePulse
Application fieldapplication as high-stable driving generator
Cathode typeoxide-yttric, indirect heating
Envelopemetal-ceramic, not-batched, mechanically tunable
Mass, kg50
Cooling methodforced water
Frequency range1808-1828MHz
Output power22kW/6MW in pulse
Frequency pulling, MHz5,5
Filament voltage, V10
Filament current, A130-180
Anode voltage, kV35-50
External loading agreement coefficient1,3
Pulse duration, uS0,5-2,2
Space factor or pulse repeating frequency0,003
