NameMI-338
TypePulse
Application fieldapplication as UHF generator in mobile equipment
Cathode typeindirect heating
Envelopemetal-ceramic, batched, mechanically tunable
Mass, kg1,2
Cooling methodNatural
Frequency range1767-1797MHz
Output power1-3kW
Frequency pulling, MHz7
Filament voltage, V6,3
Filament current, A2,4-2,8
Anode voltage, kV2,0-2,3kV
External loading agreement coefficient1,2-1,5
Pulse duration, uS0,5
Space factor or pulse repeating frequency450-460Hz
