NameMI-339
TypePulse
Application fieldapplication in navigation radars
Cathode typeoxide, indirect heating
Envelopemetal-ceramic
Mass, kg1,7
Cooling methodforced air
Frequency range3050-3070MHz
Output power25kW
Frequency pulling, MHz10
Filament voltage, V6,3
Filament current, A2,4-2,8
Anode voltage, kV7,7
External loading agreement coefficient1,35
Pulse duration, uS0,07-1
Space factor or pulse repeating frequency0,0002-0,001
