NameMI-345
TypePulse
Application fieldapplication as generator
Cathode typeindirect heating
Envelopemetal-ceramic, batched, magnetically shielded, mechanically tunable
Mass, kg5,5
Cooling methodNatural
Frequency range8845-8855MHz
Output power550kW
Filament voltage, V6,3
Filament current, A4,5-5,5
Anode voltage, kV26-30
External loading agreement coefficient1,1
Pulse duration, uS0,8-1
Space factor or pulse repeating frequency0,0001-0,00025
