NameMI-84A
TypePulse
Application fieldapplication as microwave generator
Cathode typeoxide, indirect heating
EnvelopeMetal, batched
Mass, kg13
Cooling methodforced air
Frequency range9520-9460MHz
Output power250-300kW
Frequency pulling, MHz15
Tuning steepness0,5MHz/A
Filament voltage, V12,6
Filament current, A4,4-4,5
Anode voltage, kV22-26
External loading agreement coefficient1,1
Pulse duration, uS1
