NameMI-88M
TypePulse
Application fieldoscillation of microwave pulses on fixed frequency
Cathode typeoxide, indirect heating
Envelopemetal
Mass, kg7,5
Cooling methodNatural
Frequency range36415-37150MHz
Output power28kW
Frequency pulling, MHz60
Tuning steepness5MHz/A
Filament voltage, V6,3
Filament current, A2,2-3,5
Anode voltage, kV11-15,0
External loading agreement coefficient1,5
Pulse duration, uS0,07-0,15
Space factor or pulse repeating frequency3-6kHz
