40LM1C

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
Name40LM1C
ApplicationAlphanumeric image reproduction
Envelopeglass, side anode
Mass, g9000
Deflection typeelectromagnetic
Beam focusingcombined
Colorfrom red to green
Resolution, lines or focused line size, mm0,4mm
Brightness, kd/sq.mred-20, green -100
Filament voltage, V6,3
Anode voltage, kV11
