45LM1V

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
Name45LM1V
ApplicationVisual registration of electrical process
Envelopeglass, side anode
Mass, g12000
Deflection typemagnetic
Beam focusingmagnetic
Colorwhite
Resolution, lines or focused line size, mm0,8mm
Brightness, kd/sq.m50n
Filament voltage, V6,3
Anode voltage, kV12
Afterglow time/color4,0-15sec, yellow-orange
