45LM2C

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
Name45LM2C
ApplicationSimultaneous optical and electronic image observation
Envelopeglass with optical window
Mass, g17000
Deflection typeelectromagnetic
Beam focusingelectromagnetic
Colorfrom red to green
Resolution, lines or focused line size, mm0,7mm
Brightness, kd/sq.mred-8, green-80
Filament voltage, V6,3
Anode voltage, kV12
Afterglow time/color0,2sec
