45LM2U

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
Name45LM2U
ApplicationVisual registration of electrical process
Envelopeglass, side anode
Mass, g12000
Deflection typeelectromagnetic
Beam focusingelectromagnetic
Colorgreen
Resolution, lines or focused line size, mm1500
Brightness, kd/sq.m200nit
Filament voltage, V6,3
Anode voltage, kV14
Afterglow time/color0,1sec
