45LM4C

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
Name45LM4C
ApplicationAlphanumeric image reproduction
Envelopeglass
Mass, g12000
Deflection typeelectromagnetic
Beam focusingelectromagnetic
Colorred-orange and pink
Resolution, lines or focused line size, mm0,5mm
Brightness, kd/sq.mred-orange-10, pink-70
Filament voltage, V6,3
Anode voltage, kV14
Afterglow time/color6 sec
