45LM5C

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
Name45LM5C
ApplicationAlphanumeric image reproduction
Envelopeglass, side anode
Mass, g12000
Deflection typeelectromagnetic
Beam focusingelectrostatic
Colorred-orange and yellow-green
Resolution, lines or focused line size, mm0,3mm
Brightness, kd/sq.mred-orange-8, yellow-green-70
Filament voltage, V6,3
Anode voltage, kV14
Afterglow time/colormoderate
