50LM1C

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
Name50LM1C
ApplicationAlphanumeric and TV image reproduction
Envelopeglass, side anode
Mass, g9500
Deflection typeelectromagnetic
Beam focusingelectrostatic
Colorred and green
Resolution, lines or focused line size, mm0,45mm
Brightness, kd/sq.mred-20, green-200
Filament voltage, V6,3
Anode voltage, kV12
