6LM1S

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
Name6LM1S
Envelopeglass, side anode
Mass, g130
Deflection degree55
Deflection typeelectromagnetic
Colororange
Resolution, lines or focused line size, mm600
Brightness, kd/sq.m20
Filament voltage, V6,3
Anode voltage, kV9
