6LM4S

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
Name6LM4S
Applicationin special equipment
Envelopeglass, side anode
Mass, g100
Deflection degree55
Deflection typeelectromagnetic
Colororange
Resolution, lines or focused line size, mm600
Brightness, kd/sq.m100
Filament voltage, V1,36
Anode voltage, kV9
