8LM3V

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
Name8LM3V
ApplicationVisual registration of electrical process
Envelopeglass, side anode
Mass, g250
Deflection typeelectromagnetic
Beam focusingelectrostatic
Coloryellow-orange
Resolution, lines or focused line size, mm0,6mm
Brightness, kd/sq.m50nit
Filament voltage, V6,3
Anode voltage, kV4

See also

11LM2G Resolution, lines or focused line size, mm0,3mm 11LM3G Resolution, lines or focused line size, mm0,3mm 11LM6V Resolution, lines or focused line size, mm0,3mm Brightness, kd/sq.m25 13LM31V Resolution, lines or focused line size, mm0,5mm Brightness, kd/sq.m60nit 13LM4V Resolution, lines or focused line size, mm0,4mm Brightness, kd/sq.m80nit 13LM56I Resolution, lines or focused line size, mm0,5mm Brightness, kd/sq.m50 13LM57D Resolution, lines or focused line size, mm0,5mm Brightness, kd/sq.m40nit 13LM58K Resolution, lines or focused line size, mm0,5mm Brightness, kd/sq.m40nit 13LM5A Resolution, lines or focused line size, mm35 13LM6S Resolution, lines or focused line size, mm0,3 Brightness, kd/sq.m50nt
