R-75

Check availability
SG2S pin diagram
Click to see in full size
NameR-75
Typeuncontrolled
Application fieldovervoltage protection
Envelopemetal-ceramic
Spark voltage, kV0,7-1,2
Anode current, A1000 in pulse
Insulation resistance, MOhm500
Pulse duration, uS250-50000

See also

R-10 Spark voltage, kV1,35-1,65 R-12 Spark voltage, kV0,128-0,192 R-18 R-18-1 R-21 Spark voltage, kV1,05-2,0 R-22 Spark voltage, kV1,9-2,5 R-23 Spark voltage, kV0,06-0,24 R-24 Spark voltage, kV2,0-5,5 R-26 Spark voltage, kV2,6-3,1 R-27 Spark voltage, kV0,31-0,39
