R-76

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameR-76
Typeuncontrolled
Application fieldcommunication lines and equipment protection
Envelopemetal-ceramic
Spark voltage, kV2,2-2,8
Spark frequency, Hz0,1
Anode current, A1000 in pulse
Insulation resistance, MOhm1000
Pulse duration, uS5-35000
Life, pulses1000
