R-77

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameR-77
Typeuncontrolled
Application fieldsymmetrical lines protection
Envelopemetal-ceramic
Spark voltage, kV0,15-0,35
Spark frequency, Hz1
Anode current, A30000 in pulse
Insulation resistance, MOhm100
Pulse duration, uS15000
