6Zh8

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
Name6Zh8
TypeHF pentode
ApplicationHF voltage amplification
Cathode typeoxide, indirect heating
Envelopemetal
Mass, g42
Socket typersh5-1
Filament voltage, V6,3
Filament current, A0,275-0,325
Anode voltage, V250
Anode current, A0,002-0,004
Anode power, W2,8
Grid1 voltage, Vminus3
Grid2 voltage, V100
Reverse grid current, uA0,5
Steepness, mA/V1,3-2,0
Microphonic noise, mV100
