NameUV-91
Application fieldUHF input amplifier
Cathode typeindirect heating
Output typecoaxial
Envelopeglass with permanent magnet focusing system in metal envelope
Mass8,5
Cooling methodnatural
Frequency range10,06-10,30cm
Gain20-30dB
Filament voltage, V1,7-2,3
Filament current, A0,2-0,26
Slow-wave circuit voltage, V60-90
Collector voltage, V400
External loading agreement coefficient2
Noise coefficient3
