NameUVF-5
Application fieldApplication as amplifier-phase changer in AFC
Cathode typeOxide, indirect heating
Output typecoaxial
Envelopeglass
Mass2,5kg
Cooling methodforced air
Frequency range991MHz
Output power3,5-8,0W
Filament voltage, V12,6
Filament current, A0,5-1,0
First anode voltage, V850-1150
Slow-wave circuit voltage, V1100-1400
Control electrode voltage, V40-160
Collector voltage, V1300-1500
External loading agreement coefficient1,3
