LI475

Check availability
SG2S pin diagram SG2S pin diagram
Click to see in full size
NameLI475
TypeVidicon
Application fieldin TV equipment
Beam focusingelectrostatic
Beam deflectionelectromagnetic
Photocathode area, mm6,6 x 8,8
Resolution, lines625
Illuminating intensity, Lux2
