LI7

Check availability
SG2S pin diagram
Click to see in full size
NameLI7
TypeImage-orthicon
Application fieldin 625-string TV equipment
Photocathode typeAntimony-Cesium-Bismuth
Beam focusingelectromagnetic
Beam deflectionelectromagnetic
Max.spectrum sensitivity, Angstrem4400-5000
Photocathode area, mm18x24
Resolution, lines625
Illuminating intensity, Lux-40
